CircleCI Followup: Deploying Via rsync

CircleCI Followup: Deploying Via rsync

This tutorial was updated on April 3, 2018.

In last week’s article, we showed you how to automate the deployment of a Hugo site using CircleCI. The example we provided used the awscli utility to deploy the results of your build process to an AWS S3 bucket. In this follow-up, we will show you how to use the rsync utility to deploy your site to any rsync-enabled server.

Why rsync?

rsync is a utility for transferring files between machines. It is a good choice for our use case because:

  • It is commonly available on Unix systems
  • It can compute and send only parts of updated files to minimize network usage and transfer as fast as possible
  • It allows us to transfer files using SSH

Unlike our AWS-specific deployment in the previous article, the rsync deployment can be used with a variety of hosting providers and is a good general-purpose solution.

Review: The .circleci/config.yml File

Recall that we are telling CircleCI how to deploy our site by inserting a configuration file at .circleci/config.yml with the following information:

version: 2
jobs:
  build:
    docker:
      - image: cibuilds/hugo:latest
    working_directory: ~/hugo
    environment:
      HUGO_BUILD_DIR: ~/hugo/public
    steps:
      - run: apk update && apk add git
      - checkout
      - run: git submodule sync && git submodule update --init
      - run: curl -L https://github.com/bep/s3deploy/releases/download/v2.0.1/s3deploy_2.0.1_Linux-64bit.tar.gz | tar xvz
      - run: HUGO_ENV=production hugo -v -d $HUGO_BUILD_DIR
      - run: htmlproofer $HUGO_BUILD_DIR --allow-hash-href --check-html --empty-alt-ignore --disable-external
      - deploy:
          name: deploy
          command: |
            if [ "${CIRCLE_BRANCH}" = "master" ]; then
              ./s3deploy -source=$HUGO_BUILD_DIR -region=us-east-1 -bucket=dwalkr-hugo-demo -path=your-subfolder
            else
              echo "Not master branch, dry run only"
            fi

In order to use rsync to deploy instead, a few things will need to be changed:

  1. The s3deploy installation step will be removed.
  2. An SSH key will be added so the CI environment can connect to the hosting server.
  3. The hostkey of the hosting server needs to be added to the CI environment’s known_hosts file.
  4. The deploy command will be altered to use rsync

Adding the SSH Key

To enable CircleCI to send files to your server via rsync, access your project’s build settings by clicking the cog next to the project name on the Builds screen. On the settings screen, locate the SSH Permissions link under the Permissions section. Click the Add SSH Key button and add your server’s hostname and the contents of the private key.

          - add_ssh_keys:
              fingerprints:
                - "xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx"

To import this key into our CI environment, we use the add_ssh_keys step. After adding the SSH key, CircleCI displays the key’s fingerprint on the settings screen. Copy this fingerprint and insert it into the above command, and our build environment will now be able to use the key.

Providing the Hostkey for Verification

When the CircleCI server attempts to connect to your host, it may prompt you to verify the host key. Prompts are the kryptonite of automation: the CI environment will hang indefinitely, waiting for a user to give it a response. It is possible to disable this verification, but adding the correct key to the known_hosts file is a much better solution. CircleCI doesn’t have a semantic solution for adding host keys, but one option is to add the host key as an environment variable. To add environment variables, go to your project settings and click on the Environment Variables link under Build Settings. Click the Add Variable button and add a new value named REMOTE_HOSTKEY with the contents of your server’s host key. To obtain the host key, run the following command in your terminal:

$ ssh-keyscan your-server-hostname.com

We can then use this variable in our build environment to add the host key to the known_hosts file:

          - run: echo $REMOTE_HOSTKEY >> ~/.ssh/known_hosts

The Deploy Command

All that’s left is to send the generated static files contained in $HUGO_BUILD_DIR to the destination server.

          - deploy:
              name: deploy
              command: |
                if [ "${CIRCLE_BRANCH}" = "master" ]; then
                  rsync -avce ssh $HUGO_BUILD_DIR your-user@your-host:/path/to/your/website
                else
                  echo "Not master branch, dry run only"
                fi

rsync has a ton of options. The following three are especially useful for our purposes:

Flag What it Does
-a This configures rsync to run in archive mode. Archive mode automatically applies several useful settings such operating recursively on directory trees, preserving symlinks, and preserving file permissions.
-v This will run rsync in verbose mode, which will provide more information to the error log in the event something goes wrong.
-c By default, rsync skips files based on the file modification time. As mentioned in the previous article, this is not optimal for static sites. With this flag, rsync will compute a checksum of each file to determine if the contents have changed.
-e ssh This tells rsync that we wish to execute commands on the remote machine via ssh.

The Final Config File

    version: 2
    jobs:
      build:
        docker:
          - image: cibuilds/hugo:latest
        working_directory: ~/hugo
        environment:
          HUGO_BUILD_DIR: ~/hugo/public
        steps:
          - run: apk update && apk add git
          - checkout
          - run: git submodule sync && git submodule update --init
          - run: HUGO_ENV=production hugo -v -d $HUGO_BUILD_DIR
          - run: htmlproofer $HUGO_BUILD_DIR --allow-hash-href --check-html --empty-alt-ignore --disable-external
          - add_ssh_keys:
              fingerprints:
                - "xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx:xx"
          - run: echo $REMOTE_HOSTKEY >> ~/.ssh/known_hosts
          - deploy:
              name: deploy
              command: |
                if [ "${CIRCLE_BRANCH}" = "master" ]; then
                  rsync -avce ssh $HUGO_BUILD_DIR your-user@your-host:/path/to/your/website
                else
                  echo "Not master branch, dry run only"
                fi

There you have it! Using this configuration you can deploy from your CircleCI environment to a variety of different hosting providers. If rsync isn’t your sauce, you can easily tweak the deploy step to run any commands in your build environment to get your files where they need to go.
